10mw Pen Type Light Source Visual Fault Locator Fiber Optic Cable Tester Test Equipment - Intl

VFL is designed for field personal who need a portable light source tool for fiber tracing,fiber routing,coutinuity testing,to locate breakpoints(bending or cracking in fiber optical cables),and poor connections,The VFL works in an OTDR dead zone and is used for end-to-end visual fiber identification.Not recommended for use on dark colored or armored cables.

product feature：

1. Quantum well LD light source

2. 2.5mm Universal Interface

3. Always, flash, 2 modes of operation

4. Constant Power Output

5. Brass shell, durable

6. Nano-technology, multi-static protection

7. Protection device with optical port

8. Pen design, easy to carry and use

9. Master switch in the pen tail pipe

10. Through fiber-coupled optical power guarantee

11. 8 hours 50 °C high temperature testing before delivery

Product parameters

Visual Fault Finder 10mw

Central Wavelength:650nm+-10nm

Output Power:10mW

Dynamic Distance:8-10km

Optical fiber Gender: singlemode, multimode

Optical Connector:2.5mm universal connector for test different ST, SC, FC interferes

Power needed: 2 AAA alkaline batteries

Operating Temperature:-20~+60 (℃)

Storage Temperature:-40~+70 (℃)

Dimension (mm):16X176

Weight:112g(Without battery)
